PANSY HOUSE
We provide continuous Technical
Support after your purchase. Feel free
to ask us anything. We will try our
best to solve your problems for you. :
)
WHAT YOU
GET:
1 Complete Set of Digital Blueprints
of Modern House, 2 Levels, 4 Beds, 1
Sofa Bed, 3 Baths House
(This is an Instant Digital Download;
no shipping is required)
3D Color
Renderings x 4 Views
Plan,
Loft Plan,
Elevations x 4,
Sections x 2,
Floor Frame Plans
x 2,
Roof Frame Plan,
3 Enlarged
Construction Details,
Materials List
with estimated quantities.
Format in Digital
JPEG or PDF, 30 to 40 pages in A4
size.
Diagonal Watermarks will not be
visible in the downloaded files you
purchase.
Electrical, Plumbing, Sewerage
Diagrams, Interior Designs, and
Kitchen Designs are sold separately.
ADVANTAGES
OF THIS DESIGN:
4 Beds, 1 Sofa Bed, 3 Baths House,
Flexible Design. You can adjust the
length of the house to any suitable
length.
(Flexible Width = 16, Fixed Length =
48')
Minimum Loft
Height is 62 (Lowest end); practical
height, no need to crawl or slouch in
loft.
Pitched Roof (No
flat roof); no water leaks, reduced
snow loads
Proper staircases
(Not ladder); Easier to use, storage
below it.
No Valley Gutters
on Roof; no leakages, minimal joints
on roof, easier to construct.
Rectangular Plans;
no odd corners, easier to build and
furnish.
Simple plan and
sections; easier to build and
pre-fabricable.
Common
of-the-shelf materials; no special
materials necessary.
Covered porch;
useful and flexible space use.
Proper toilet,
shower and kitchen sizes; practical
and user friendly
All Roofs, Walls
and Floor can accommodate
insulation up to 6 thick
Stoves, wood
stoves, chimneys can be added.
Construction
joints details, framing plans, roofing
plans, footing plans, Doors and
Windows Schedules are included.
Comprehensive
design drawings and material list;
user friendly, easy to understand.
Guaranteed to
comply with building codes;
exchangeable or refundable if it
doesnt.
Flexible length;
can be shorten or elongated.
All materials are available
off-the-shelf from your local hardware
stores. Sizes are standard easily
available sizes. We dont use any
specialist materials that are hard to
source. Easy to prefab and install.
Minimal in-situ works, most work can
be prefabricated in a factory. Only
the concrete footings need to be cast
onsite. The rest of the materials can
be prefabricated and delivered to site
pre-built and pre-finished. All metals
frames can be pre-welded in factory
and will fit into the back of a lorry.
We designed this house for Time, Labor
and Costs savings. The site footing
casting can be done by one team of
workers while the materials are being
pre-built in the factory by another
team of workers, thus saving time.
This way you dont have to wait until
your footings are completed to start
the fabricating walls and
floors. Building in a factory
has many advantages such as quality
and precision control. Minimal
wastage. And you can work under any
weather conditions. Your house can be
built by 2 separate team of workers
working simultaneously, saving time
and costs.
All of our roofs are sloping to
eliminate rain, snow and leaves
accumulating on them. We use roof
overhangs to prevent rain/snow splash
and summer sun from heating up the
house.
All Roofs, Walls, And Floors can be
insulated with 2 to 6 Thick
Insulation Batts, Sprayed-in
Insulation Foams and Bubble Sisalation
Foils. Electric or Woodstoves,
Chimneys, Washers, can be installed
inside. Interior space is quite
spacious.
We designed this house for to maximize
your land use. You will get a full
loft floor, entire house under one
roof. Every part of the house gets a
view outside. The build-up area vs.
materials used is very high and
efficient.
It has a generous covered porch area
that can be used as dining, sitting
and exercise space. Its a very
flexible use of space. High
windows are designed for natural light
penetration to the house. The living
area, kitchen, toilets, dining are all
on the same level. Sleeping area is at
the loft above. Solar panels can be
installed on the roof.
The architecture is unique and
elegant. The materials and colors are
designed to complement your
environment.
It can be extended.
DESCRIPTION
OF HOUSE:
Level 1:
1 Covered Porch
2 Bedrooms
1 Sofa Bed
1 Hanging Bed
Living,
Dining,
1 Bathroom,
Kitchen,
1 Laundry Utility
/Closets / Storage,
Level 2 :
2 King Bed
Bedrooms and Study Table
OR
2 Queen Bed
Bedrooms and Study Table
OR
2 Single Beds
Bedrooms and Study Table
Closet / Storage
Space
2 Ensuites
2 Walk-in
Wardrobes
1 Covered Porch
SIZES:
LEVEL 1:
Enclosed (With Walls) Interior
Space
= (16 x 16) x 2 = 512 square feet.
Covered Porch (No
Walls)
= 16 x 16 = 256 square feet.
LEVEL 2:
Enclosed (With Walls) Interior
Space
= (16 x 16) x 2 = 512 square feet.
Covered Porch (No
Walls)
= 16 x 16 = 256 square feet.
------------------------------------------------------------------------------------------
Total Interior Space (With Walls,
Level 1 + Level 2) = 512 + 512 =
1,024 square feet.
Total Covered Footprint
Area
= 16 x 48 = 768 square feet.
Overall footprint of house
is
= 16 x 48 = 768 square feet.
MATERIALS:
Metal Frame, dry floor and wall
construction (cement fiber board,
timber board, glass, plywood, etc.),
Metal or Shingles roofing, Concrete
Footings, Metal stumps, Insulation
Batts with Sisalation Foil or Spray-On
Insulation Foam. You can get all the
materials from your local hardware
stores.
ESTIMATED COSTS (Ballpark Figures
only):
South = @ $190 to $225 /SF
Midwest = @ $120 to $350 /SF
Northeast = @ $220 to $330 /SF
West = @ $120 to $320 /SF
Estimated Costs of materials only =
USD60, 000. (For owners who are
building this house without hired
labor).
The best way to get a cost estimate is
to ask your local builder for the rate
$/Sq Ft. Multiply that with the total
size of the house and you will get a
rough estimate of the whole lot.
Material cost is around one third of
that.
BUILDING
DESIGN:
There are 3 ways you can get a
Building Design:
A) Buy our
Ready-Made Plan or
B) We Modify a
Ready-Made Plan for you or
C) Commission us to
Design a New one for you.
2a. Buy A Ready-Made Building Plan;
Instant Digital Download. (See Etsy
Shop: ArchitectChin,
https://www.etsy.com/shop/ArchitectChin?section_id=30842512):
Tiny House
Plan
250
3 Bed House
Plan
420
One house plan is licensed for 1 house
only. Add USD80 for each additional
house planned.
2b. We Modify a Ready-Made Plan For
You:
After you purchase a Ready-Made Plan
(Tiny House Series only) and If you
need to modify a Ready-Made Plan:
Minor Modification to Ready-Made Plan
(Width (Gable Side) remains the same,
Length is modified; i.e. the building
shape remains, it becomes longer or
shorter.):
a) A simple
thumbnail pencil sketch to modify it
is FREE (1 Plan and 1 Elevation.).
OR
Minor Modification to Ready-Made Plan
(Width (Gable Side) remains the same,
Length is modified; i.e. the building
shape remains, it becomes longer or
shorter.):
A set of CAD drawings changes to a
standard 2 D drawings (i.e. plans x 2,
elevations x 4, and sections x 2) will
be 600 USD. No 3D
views.
2c. Commission Us To Design A New One
For You:
(New Set of Plan. i.e. Width (Gable
Side) changes, Length is modified.
i.e. All dimensions differ from the
Ready- Made Plans):
1 Level
House #Complete Set
of
Drawings
$1,250
#A New Set of Plan in 2D (i.e. Plans x
2, Elevations x 4, Sections x 2, 3
Enlarged details, Floor Frame Plans,
Roof Frame Plan, Material List) No 3D
views
The 1st draft will be ready in 3
weeks. Its about 4 to 6 weeks work in
total. This is a commissioned work. No
purchase of Standard Plan is required.
Pencil Sketches will be ready in 1 or
2 Days for your comments first.
If OK, we will proceed to CAD
Drawings.
Let me know which option works best
for you and I will try my best to
accommodate your request.
You can check out our other House
Plans here:
https://www.etsy.com/shop/ArchitectChin?ref=seller-platform-mcnav§ion_id=30842512
And Our Website:
http://www.architectchin.com/index.html
I will personally reply your messages
within 1 day. We offer friendly,
helpful and honest services.
We will give you continuous technical
support.
Our designs comply with building codes
in all countries. (Including USA and
Canada).
We have 34 years of experience in
architecture. We stand by our quality.
If you are not happy with our
ready-made plans we can exchange
another one for you free of charge or
und you (minus Etsy's fees). No issue.
