LOTUS HOUSE A
We
provide continuous Technical Support
after your purchase. Feel free to ask us
anything. We will try our best to solve
your problems for you. : )
WHAT YOU GET:
1 Complete Set of Digital Blueprints of
Modern 2 Levels, 1 Bed, 1 Bath House
(This
is an Instant Digital Download; no
shipping is required)
3D Color Renderings x 4 Views
Plan,
Loft Plan,
Elevations x 4,
Sections x 2,
Floor Frame Plans x 2,
Roof Frame Plan,
3 Enlarged Construction Details,
Materials List with estimated
quantities.
Format in Digital JPEG or PDF in A4 size
Diagonal
Watermarks will not be visible in the
downloaded files you purchase.
ADVANTAGES OF THIS DESIGN:
1 Beds, 1 Bath Modern House, 1 Sofa Bed,
Flexible Design, You can adjust the
length of the house to any suitable
length.
(Fixed
Width = 24, Flexible Length = 16')
All
materials are available off-the-shelf
from your local hardware stores. Sizes
are standard easily available sizes. We
dont use any specialist materials that
are hard to source.
All
of our roofs are sloping to eliminate
rain, snow and leaves accumulating on
them. We use roof overhangs to prevent
rain/snow splash and summer sun from
heating up the house.
All
Roofs, Walls, And Floors can be
insulated with 2 to 6 Thick Insulation
Batts, Sprayed-in Insulation Foams and
Bubble Sisalation Foils.
Electric
or Woodstoves, Chimneys, Washers, can be
installed inside. Interior space is
quite spacious.
We
designed this house for to maximize your
land use. You will get a full loft
floor, entire house under one roof.
Every part of the house gets a view
outside. The build-up area vs. materials
used is very high and efficient.
It
has a generous covered porch area that
can be used as dining, sitting and
exercise space. Its a very flexible use
of space. High windows are
designed for natural light penetration
to the house. The living area, kitchen,
toilets, dining are all on the same
level. Sleeping area is at the loft
above. Solar panels can be installed on
the roof.
The
architecture is unique and elegant. The
materials and colors are designed to
complement your environment.
It
can be extended at the front and rear
end in future.
DESCRIPTION OF HOUSE:
Level 1:
1 Covered Porch
Living,
Dining,
Bathroom,
Kitchen,
Laundry for Washer and Dryer.
Closets / Storage / Pantry,
Level 2 (Loft):
1 King Bed and Study area option
Or
2 Queen Beds option
Or
3 Single Beds option
Or
1 Queen/Single Bed and Study area option
1 loose wardrobe space,
A proper Staircase
SIZES:
LEVEL 1:
Enclosed
(With Walls) Building Area
= 16 x 24 = 384 square feet.
Covered
Porch and Balconies (No Walls)
= 2 x (4 x 24) + 2 x (4 x 12)= 292
square feet.
Uncovered
Porch
= 10 x 24 = 240 square feet.
LEVEL 2:
Enclosed
(With Walls) Building Area
= 12 x 24' = 288 square feet.
------------------------------------------------------------------------------------------
Total Enclosed Area (With Walls, Level 1
+ Level 2)
= 384 + 288 = 672 square
feet.
Total
Covered Footprint Area
= 24' x 24' = 576 square feet.
Overall
footprint of house is
= 24' x 34' = 816 square feet.
MATERIALS:
Metal Frame, dry floor and wall
construction (cement fiber board, timber
board, glass, plywood, etc.), Metal or
Shingles roofing, Concrete Footings,
Metal stumps, Insulation Batts with
Sisalation Foil or Spray-On Insulation
Foam. You can get all the materials from
your local hardware stores.
ESTIMATED COSTS (Ballpark Figures only):
South = @ $190 to $225 /SF
Midwest
= @ $120 to $350 /SF
Northeast
= @ $220 to $330 /SF
West
= @ $120 to $320 /SF
Costs of materials only = USD27, 000.
(For owners who are building this house
without hired labor)
BUILDING DESIGN:
There are 3 ways you can get a Building
Design:
A)
Buy our Ready-Made Plan or
B)
We Modify a Ready-Made Plan for you or
C)
Commission us to Design a New one for
you.
2a. Buy A Ready-Made Building Plan;
Instant Digital Download. (See Etsy
Shop: ArchitectChin,
https://www.etsy.com/shop/ArchitectChin?section_id=30842512):
Tiny House Plan
250
3 Bed House Plan
420
One
house plan is licensed for 1 house only.
Add USD80 for each additional house
planned.
2b. We Modify a Ready-Made Plan For You:
After
you purchase a Ready-Made Plan (Tiny
House Series only) and If you need to
modify a Ready-Made Plan:
Minor
Modification to Ready-Made Plan (Width
(Gable Side) remains the same, Length is
modified; i.e. the building shape
remains, it becomes longer or shorter.):
a) A simple thumbnail
pencil sketch to modify it is FREE (1
Plan and 1 Elevation.).
OR
Minor
Modification to Ready-Made Plan (Width
(Gable Side) remains the same, Length is
modified; i.e. the building shape
remains, it becomes longer or shorter.):
A
set of CAD drawings changes to a
standard 2 D drawings (i.e. plans x 2,
elevations x 4, and sections x 2) will
be 600 USD. No 3D
views.
2c. Commission Us To Design A New One
For You:
(New
Set of Plan. i.e. Width (Gable Side)
changes, Length is modified. i.e. All
dimensions differ from the Ready- Made
Plans):
1 Level
House #Complete Set of
Drawings
3,738
2 Levels
House #Complete Set of
Drawings
4,438
3 Levels
House #Complete Set of
Drawings
4,938
#A New Set of Plan in 2D (i.e. Plans x
2, Elevations x 4, Sections x 2, 3
Enlarged details, Floor Frame Plans,
Roof Frame Plan, Material List) and 3D
views (2 Interior and 2 Exterior views).
The
1st draft will be ready in 3 weeks. Its
about 6 to 8 weeks work in total. This
is a commissioned work. No purchase of
Standard Plan is required.
Let me know which option works best for
you and I will try my best to
accommodate your request.
You
can check out our other House Plans
here:
https://www.etsy.com/shop/ArchitectChin?ref=seller-platform-mcnav§ion_id=30842512
And
Our Website:
http://www.architectchin.com/index.html
I
will personally reply your messages
within 1 day. We offer friendly, helpful
and honest services.
We
will give you continuous technical
support.
Our
designs comply with building codes in
all countries. (Including USA and
Canada).
We
have 34 years of experience in
architecture. We stand by our quality.
If
you are not happy with our ready-made
plans we can exchange another one for
you free of charge or refund you (minus
Etsy's fees). No issue.
